Dwide wall
21893 Dwide 21893
Wall luminaire, height 600 mm, with Direct/Indirect light distribution 90/10. Opal divider for good anti-glare dimming at eye level.
Installation
Luminaire for wall installation. Two securing holes.
Connection
Cable entry from rear or external cable. 5-way snap-in terminal block, 1-phase through-wiring possible.
Design
Metal luminaire body with die-cast metal ends, white (RAL 9016) finish. The rear is covered by an opal diffuser for indirect light, which also works as a dust cover.
Louvre
Light divider in opal acrylic (PMMA).
Light distribution
Direct/Indirect.
Dimming
DALI/phase-pulse control as standard. Luminaire with DALI/phase pulse control and CLO (Constant Light Output) as standard.
e-Sense Flex – Integrated sensors with ambient light sensor. Presence/absense control high/low/off. Wireless communication via Bluetooth mesh, equipped with microwave sensor.
Designed by
Yellon.
Miscellaneous
CRI 90 alt CLO L100 100 000h available upon request. CLO (Constant Light Output) means that the luminaire provides the same amount of light for the duration of its specified burn-time.
Media
Dwide Wall – Installation
Dwide
Dwide is a complete, versatile product family that meets all lighting requirements – whether for office, school or hospital projects. Recessed, ceiling-mounted and pendant luminaires with different light distributions are...
More about the family Dwide
