22347-402 Dwide corner

Module

1200

Light distribution

Direct

Louvre

Delta

Colour

White

Lumen output

2935

CLO function active

Yes

CLO time, h

100000

lm/W

149

CCT, K

4000

CRI

80

SDCM

3

Melanopic DER

0.650

Lumen maintenance 100 000 h

L100

LED driver, h/max failure %

100000/10

Energy class, LED module

C

PstLm

1.000

SVM

0.300

Light control

DALI/Phase-pulse

Driver brand

Philips

DALI generation/adress type

Dali-2/1xDT6

Power on last level

Yes

Corridor function

Yes

Switch control, max no.

30

AM

Yes

ZD4i Certified

False

Daylight functionality

False

Rated supply voltage, V

220-240

Mains frequency, Hz

0, 50, 60

Protective class

1

IP rating

20

Start W

20

End W

23

Average W

21

Stand by W

0.24

Min. ambient temperature, °C

-25

Max. ambient temperature, °C

25

MCB B10A, pcs

15

MCB B16A

25

MCB C10A

26

MCB C16A

42

THD, %

14

Surge protection CM, kV/kA

2

Surge protection DM, kV/kA

1

Leakage current PE

0.500

Power factor, 100 %

0.96

Length, mm

1164

Width, mm

126

Height, mm

66

Weight, kg

3.6
